Steel Pinion 48dp - 38t

FEATURES:
Material: Steel
Pitch: 48dp
Motor Shaft Mount
Ø: 3.175mm
Pinion Length: 9mm
Pinion
Ø: see list below
Art.-No.          Teeth:        Pitch /
Ø
:
2310270        13T           48dp / Ø 7.950mm
2310271        14T           48dp / Ø 8.480mm
2310272        15T           48dp / Ø 9.010mm
2310273        16T           48dp / Ø 9.540mm
2310274        17T           48dp / Ø 10.070mm
2310275        18T           48dp / Ø 10.600mm
2310276        19T           48dp / Ø 11.130mm
2310277        20T           48dp / Ø 11.660mm
2310278        21T           48dp / Ø 12.190mm
2310279        22T           48dp / Ø 12.720mm
2310280        23T           48dp / Ø 13.250mm
2310281        24T           48dp / Ø 13.780mm
2310282        2
5T           48dp / Ø 14.310mm
2610283        26T           48dp / Ø 14.840mm
2310284        27T           48dp / Ø 15.370mm
2310285        28T           48dp / Ø 15.900mm
2310286        29T
48dp / Ø 16.430mm
2310287        30T
48dp / Ø 16.960mm
2310288        31T
48dp / Ø 17.490mm
2310289        32T
48dp / Ø 18.020mm
2310290        33T
48dp / Ø 18.550mm
2310291        34T
48dp / Ø 19.080mm
2310292        35T
48dp / Ø 19.610mm
2310293        36T
48dp / Ø 20.140mm
2310294        37T
48dp / Ø 20.670mm
2310295        38T
48dp / Ø 21.200mm
2310296        39T
48dp / Ø 21.730mm
2310297        40T
48dp / Ø 22.260mm
2310298        41T
48dp / Ø 22.790mm

Item number: 2310295
EAN: 4250650950385
