Servo Hd B8rs Brushless Low Pr Mg SSR Program (30kg/0.075s) for 1/10

Description

New Power HD B8-RS brushless servo is now available.

Fine-tuned in collaboration with pro drivers, its ultra-lightweight design (at just 55 g) makes it ideal for 1/10-scale on-road and electric-buggy racing at a friendly price point

• Voltage range: 6.0–8.4 V (at 8.4 V delivers 30 kg·cm torque at 0.075 s speed)

• 18 cm black servo lead

• Steel gears

• All engineered for ultra-lightweight setups, low current draw, massive torque and razor-sharp response

Supports high-speed protocols on all major radios:

• FLYSKY Noble NB4+ Pro: NOR / SR / SFR

• FUTABA: NOR / SR / UR

• SANWA: NOR / SHR / SSR / SUR / SXR

Programmable via Power HD servo program box PG-CB63.

Torque(6.0V): 36.0 kg-cm / (499.9 oz/in)
Torque(7.4V): 42.0 kg-cm / (583.3 oz/in)
Torque(8.4V): 50.0 kg-cm / (694.4 oz/in)
Torque(6.0V): 20.0 kg-cm / (277.7 oz/in)
Torque(7.4V): 26.0 kg-cm / (361.1 oz/in)
Torque(8.4V): 30.0 kg-cm / (416.6 oz/in)
Speed: 0.097 sec (6.0V) │ 0.085 sec (7.4V)
Speed: 0.075 sec (8.4V)
Operating Voltage: 6.0 ~ 8.4 DC Volts
Weight: 55 g (1.94 oz)
Bearing Type: Ball Bearing x 2
Motor Type: Brushless Motor
Gear Type: 7075+Steel
Max current: 3.0A
Working frequency: 1520μs / 333hz
Size: 41.0 x 20.0 x 29.0 mm ( 1.61 x 0.79 x 1.14 in)
Compatible with program box only
