Hobbywing Ezrun Mini28 Brushless Speed Control

HOBBYWING EZRUN MINI28 SPEED CONTROL

The Hobbywing EzRun MINI28 Sensored Brushless ESC is a high-performance, ultra-compact speed controller designed specifically for 1/28th scale racing models. Measuring just 22.7 × 14.2 × 11.8mm and weighing only 5g, it delivers powerful 30A continuous / 80A peak output while maintaining low operating temperatures thanks to its full-alloy heatsink.

Compatible with sensored and sensorless 1626-size motors on 2S LiPo, it features a built-in adjustable 6V/7.4V BEC, dual racing modes (Blinky & Modified), and 26 programmable parameters including Boost and Turbo. Fully programmable via the LCD Pro Program Box or OTA Bluetooth module for quick setup and seamless firmware updates through the Hobbywing app.

Specification

For: 1/28 RC mini car
Colour: Black
Continuous & Peak Current: 30A/80A
Maximum Cell Count: 2S LiPo
BEC Output: 6V/7.4V @ 3.5 amps
Size: 22.7 x 14.2 x 11.8mm
Weight: 5 grams (without wires)
Works with: 1626 sized motors (not included)
Programming: LCD G2 Program Box, OTA Programmer (not included)
Includes: Hobbywing EZRUN MINI28 Brushless Sensored ESC (1 pc)
Motor Type: Brushless
Sensor Type: Sensored
